100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor

FPR-V

Start Port:

Ningbo/Shanghai

Payment:

T/T

MOQ:

1 set

Model:

FPR-V

Delivery time:

15-20 days

Certification:

Main conveyor components with CE

Inquiry

Write a Review

FPR-V

FLEXIBLE POWERED ROLLER CONVEYOR-V BELT

V Belt Flexible Motorized Roller Conveyor is more strong than O Belt type. The side links and legs joint structure is reinforced. Thickness of X shape side links increased to 5mm. Motors power changed from 90W to 120W.Motor numbers also increased.

TECHNICAL PARAMETERS

Belt	High quality Yuanyang V belt
Roller	Dia 50*1.5mm galvanized steel roller, Max. gap138mm center to center
Motor	90W/120W electronic governor motor
Frame	5mm thickness reinforced X shape side links
Leg	32×32 powder coated tube with 25×25 galvanized tube inside
Caster	5" high quality swivel lockable polyurethane casters
Control Box	Forward/Stop/Reverse
Frequency Inverter	Delta

MODEL LIST

Model	Open Length (mm)	Close Length (mm)	Roller Width (mm)	AdjustableHeight (mm)	VariableSpeed (m/min)	Max.Load (kg/㎡)	Motor Power (w)
FPR-V4.8	4800	2040	600/800	700-1000	10-20	100	450
FPR-V6	6000	2550	600/800	700-1000	10-20	100	540
FPR-V7.2	7200	3060	600/800	700-1000	10-20	100	630
FPR-V.48	8400	3570	600/800	700-1000	10-20	100	720
FPR-V9.6	9600	4080	600/800	700-1000	10-20	100	810
FPR-V10.8	10800	4590	600/800	700-1000	10-20	100	900
FPR-V12	12000	5100	600/800	700-1000	10-20	100	990
FPR-V13.2	13200	5610	600/800	700-1000	10-20	100	1080
FPR-V14.4	14400	6120	600/800	700-1000	10-20	100	1170
FPR-V15.6	15600	6630	600/800	700-1000	10-20	100	1260
FPR-V16.8	16800	7140	600/800	700-1000	10-20	100	1350
FPR-V18	18000	7650	600/800	700-1000	10-20	100	1440
FPR-V19.2	19200	8160	600/800	700-1000	10-20	100	1530
FPR-V20.4	20400	8670	600/800	700-1000	10-20	100	1620

SHOW DETAILS

100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor 8

Dia 50mm galvanized steel rollers

100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor 9

Rollers are driven by V belt

100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor 10

Every meter with one 90W min motor

100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor 11

Suitable to transport paper bags

100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor 12

Each legs with adjustable height of 700-1000mm

100KG Load Capacity Heavy Duty Flexible Powered Roller Conveyor 13

Mobile on 5" universal castors

Our Cases - what we finished

So far we have cooperated with one Bangladeshi tea factory for 10 years，providing hundreds of machines.They choose to work deep with us because we offer high-quality products and service at more competitive prices.

Optional Functions - what we can also do

This system represents a robust, efficient, and highly adaptable solution for modern material handling, ensuring your cartons move smoothly and remain in perfect order from start to finish.
