Flexible Gravity Stainless Steel 304 Roller Conveyor | FGR-SUS304
FGR-SUS304
FLEXIBLE GRAVITY STAINLESS STEEL ROLLER CONVEYOR
Flexible Gravity Stainless Steel 304 Roller Conveyor is designed especially to convey flat base loads,such as different sized boxes, cases and cartons, etc. It can be expanded if you require a longer system or bent into curves or even compacted for better storage when not in use. What’s more, this conveyor is very easy to quick manoeuvre in or out of trucks for faster, safer, easier loading and unloading materials.
TECHNICAL PARAMETERS
Roller | Φ 50*1.5mm stainless steel 304 roller, Max. gap 130mm center to center |
Frame | 2mm thickness galvanized steel plates with better load |
Legs | With adjustable height |
Caster | Φ 100mm high quality swivel lockable polyurethane casters |
MODEL LIST
Model | Open Length | Close Length | Effective Width | Adjustable Height | Load Capacity | Roller Dia | Roller Material |
FGR-SUS-4 | 4m | 1.7m | 600mm | 620-990mm | 50kg/m | 50mm | Stainless steel 304 |
FGR-SUS-5 | 5m | 2.1m | 600mm | 620-990mm | 50kg/m | 50mm | Stainless steel 304 |
FGR-SUS-6 | 6m | 2.5m | 600mm | 620-990mm | 50kg/m | 50mm | Stainless steel 304 |
SHOW DETAILS
