    This cement bag loading conveyor is a telescopic motorized roller conveyor designed for efficiently loading and offloading cement bags. This innovative system is equipped with motorized rollers that can extend and retract, allowing for seamless movement of heavy cement bags. The conveyor facilitates the smooth and safe transfer of bags from trucks or storage areas to the desired location, streamlining the loading and unloading process. Its telescopic design enables flexibility in reaching different areas of the workspace, while the motorized feature enhances efficiency and reduces manual labor. With its ability to handle heavy loads and optimize workflow, the cement bag loading conveyor is an essential solution for the logistics and construction industry.


    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 6

    FPR-RV

    V BELT FLEXIBLE MOTORIZED RUBBER COATED ROLLER CONVEYOR

    V Belt Flexible Powered Rubber Coated Roller Conveyor is an extendable powered automatic roller conveyor with controllable conveying speed & direction and adjustable supporting leg height. Having enough power supply by one mini motor per section, it is well qualified to intensively transport goods especially with flat bottom in the warehouse/storehouse, workshop, factory, harbor, dock, etc. In addition, it can be applied to such situations as production-packing line, temporary conveying line and goods distribution line. It satisfies the easy, quick and efficient goods delivery.

    Yifan Conveyor presents a cutting-edge loading and unloading solution that revolutionizes the handling of cement bags in logistics and construction operations. With its state-of-the-art design and precision engineering, the Yifan Conveyor sets a new standard for efficiency and safety in material handling. This innovative system not only streamlines the process of transferring heavy loads but also enhances productivity by reducing manual labor and optimizing workflow. Trusted by industry professionals worldwide, the Yifan Conveyor is synonymous with reliability, durability, and top-notch performance, making it a preferred choice for businesses looking to improve their operational efficiency and maintain a competitive edge in the market.

    TECHNICAL PARAMETERS

    Belt

    high quality V belt

    Roller

    dia 55mm rubber coated roller, Max. gap138mm center to center

    Motor

    90W/120W electronic governor motor

    Frame

    5mm thickness galvanized curved join plates with better load

    Leg

    32×32 powder coated tube with 25×25 galvanized tube inside

    Caster

    5" high quality swivel lockable polyurethane casters

    Control Box

    Forward/Stop/Reverse, Emergency Stop, Speed Knob

    Frequency Inverter

    Delta

    MODEL LIST

    Model

    Open Length
    (mm)

    Close Length
    (mm)

    Rpller Width
    (mm)

    Adjustable Height
    (mm)

    Variable Speed
    (m/min)

    Max.Load
    (kg/㎡)

    Motor Power
    (w)

    FPR-RV-4.8

    4800

    2200

    600/800

    700-1000

    10-20

    100

    450

    FPR-RV-6

    6000

    2750

    600/800

    700-1000

    10-20

    100

    540

    FPR-RV-7.2

    7200

    3300

    600/800

    700-1000

    10-20

    100

    630

    FPR-RV-8.4

    8400

    3850

    600/800

    700-1000

    10-20

    100

    720

    FPR-RV-9.6

    9600

    4400

    600/800

    700-1000

    10-20

    100

    810

    FPR-RV-10.8

    10800

    4950

    600/800

    700-1000

    10-20

    100

    900

    FPR-RV-12

    12000

    5500

    600/800

    700-1000

    10-20

    100

    990

    SHOW DETAILS

    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 7
    5mm thick side links
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 8
    Each leg install one 120W motor
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 9
    Add a gravity roller in the middle with better support to bags
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 10
    Control Box: load, stop, unload, Emergency Stop
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 11
    Rollers driven by V belt
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 12
    PU stripped roller with high grip

    Application 1

    Rubber coated rollers with good friction to bags. This conveyor usually be used for loading and unloading bags.

    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 13
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 14
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 15
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 16

    Application 2

    Loading 50KG bags from warehouse directly into trucks

    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 17
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 18

    Application 3

    Unloading fabric rolls from containers to warehouse in Textile and garment factory

    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 19
    50KG Cement Bags Loading and Offloading Telescopic Motorized Roller Conveyor 20
