Overview

Quick Details

Applicable Industries:Garment Shops, Food & Beverage Factory, Home Use, Retail, Food Shop, Food & Beverage Shops, Other, Advertising Company, E-business Warehouse, Distribution Center, Store, Third Party Logistics, Packaging Company

After Warranty Service:Video technical support, Online support

Local Service Location:None

Showroom Location:None

Condition:New

Material:Carbon Steel

Material Feature:Oil Resistant

Structure:Conveyor System

Place of Origin:NINGBO,China

Brand Name:YiFan

Voltage:220V/380V

Power:other

Dimension(L*W*H):L5000*W600*H700/2500mm

Certification:CE

Warranty:1 Year

After-sales Service Provided:Free spare parts

Width or Diameter:600mm

Machinery Test Report:Provided

Video outgoing-inspection:Provided

Marketing Type:Hot Product 2021

Warranty of core components:1 Year

Core Components:Motor, Bearing

Weight (KG):600 kg

Belt Width:600mm

Belt Material:PVC

Conveyor Height:700-2500mm

Adjustable Speed:10-20m/min

Load Capacity:50kg/m

Video Description

Product Overview

FOLDABLE TRUCK LOADING CONVEYOR （TLC-F600)

Front Elevation

Left elevation

Right Elevation

Drawing

Technical Parameters

1.Belt Specs:W=600,T=5mm,rough top PVC belt 2.Adjustable Speed:10-20m/min,foward & reverse 3.Adjustable Height:700-2500mm 4.Load Capacity:50kg/m 5.Lift Motor:2.2kw;Belt Motor:1.5kw 6.Power Supply:380V,3-PH,50Hz or 220V,1-PH,50Hz 7.Packing Size:L3000*W1200*H1000,3.6CBM,G.W.:730KGS

Packing and Shipping

One 20ft container can load 2nos of TLC-F600

One 40ft container can load 4nos of TLC-F600

Successful Project

2012 Project In Mombasa,Kenya

Loading soap bar cartons from store area directly into 20ft & 40ft containers by TLC-P600 & FPR The TLC-P600 combine with flexible expandable powered roller conveyor is the most safe, easy and efficient way for plant warehouse, E-commerce stores and courier company distribution center to load unload all kinds of container/vehicles/trailers/vans/trucks.

2013 Project In Mombasa,Kenya Loading 25KG soft powder bags directly from warehouse into 40ft containers by TLC-600 & Mobile Belt Conveyor

We have rich experience in loading 50KG flour/rice/fertilizer bags to trucks/containers by truck loading conveyor, flexible powered roller conveyor and mobile belt conveyor.

2014 Project In Bangladesh Transport 60KG tea bags from 2nd floor to ground floor and loading into trucks by TLC-P600

Adopt flexible powered PU rollers conveyor to ransport 50KGS tea bags from 2nd floor store house and go down on vertical lifting conveyor to ground floor, directly load into trucks by TLC-P600.

2015 Project In Kenya Unloading 10ltr and 20ltr Edible Oil Jerry Cans from Vans by TLC-600

Flexible powered roller conveyor is very popular in store house with limit space, as it can take curve freely. After unloading the jerry cans from the vans, it go freely inside the storeroom.

2016 Project In Kenya Cartons loading unloading container/trucks/trailers

Truck Loading Conveyor combine with mobile belt conveyor, 90 degree curve roller conveyor for loading unloading all kinds of cartons/boxes/bags

2016 Project In Kenya Bags stacking mobile belt conveyor

Bags Stacking Mobile Belt Conveyor combine with straight PVC belt conveyor for loading unloading and stacking all kinds of cartons/boxes/bags
