Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers

    oops...!

    no product data.

    Go to homepage
    Overview
    Quick Details
    Applicable Industries:Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other, Hotels, Restaurant
    After Warranty Service:Video technical support, Online support, Spare parts
    Local Service Location:None
    Showroom Location:None
    Condition:New
    Material:Carbon Steel
    Material Feature:Fire Resistant
    Structure:Roller Conveyor
    Place of Origin:Zhejiang, China
    Brand Name:YiFan
    Voltage:No motor
    Power:no power
    Warranty:1 Year
    After-sales Service Provided:Free spare parts
    Width or Diameter:600mm
    Machinery Test Report:Not Available
    Video outgoing-inspection:Provided
    Marketing Type:Hot Product 2020
    Warranty of core components:1 Year
    Core Components:Roller
    Weight (KG):600 kg
    Open Length:16900mm
    Close Length:4800mm
    Loading Height in Vehicle:818-1198mm
    Width:600/800mm
    Rack:carbon steel
    Video Description
    Product Overview

    TBR-12 Telescopic Gravity Unloading Roller Conveyor


    This gravity conveyor is a development of the highly successful telescopic. Mounted on a large robust box section chassis with an adjustable platform which suits most tailboard heights. Fully welded steel construction giving stability & strength. Low inertia 50mm dia PVC rollers set at 65mm centres allows transportation small & large parcels.

    Each deck of track is independently height adjustable by means of A screw jack allowing correct gravity fall. Smooth transfer between Decks is achieved by a series of 25mm dia steel rollers within a transfer slider section. Intended for off-loading only without the need of a loading dock, the telescopic can be used in conjunction with other conveyor from our extensive range to reach all areas of the warehouse.
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 6
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 8
    Technical Parameters
    Main Roller
    Φ50mm, Transfer Roller: Φ25mm galvanized steel rollers
    Open Length
    16900mm
    Close Length
    4800mm
    Declined Section Length
    4000mm
    Effective Width
    600mm
    Loading Height in Vehicle
    818-1198mm
    Discharge Height outside Vehicle
    970-1350mm
    Overall Length in Vehicle
    12m
    Successful Project
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 10
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 12
    Company Profile
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 14
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 16
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 18
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 20
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 22
    Robust adjustable height Telescopic Gravity Roller Conveyor for Unloading Containers 24
    FAQ
    Please feel free to contact us at sales02@yfconveyor.com if you have any other questions.
    How long is the production time?
    YIFAN: flexible conveyor takes 1-2 weeks; truck loading conveyor and telescopic belt conveyor takes 3-4 weeks

    What is the MOQ?
    YIFAN: 1 unit

    Can your company provide OEM & ODM service?
    YIFAN: yes

    Can you do customized conveyors?
    YIFAN: yes

    Do you offer installation service abroad?
    YIFAN: yes

    What is the payment terms?
    YIFAN: T/T,LC,

    What is the delivery port?
    YIFAN: Ningbo/Shanghai

    How many years have you been in this industry?
    YIFAN: 10 years

    What is the HS code?
    YIFAN: 84283300,84283920,84283990

    Is YIFAN a trading company or factory?
    YIFAN: we are a trading company but have long-term cooperation factory, who only supply from us.

    Which industry can your conveyors be applied to?
    YIFAN: our conveyors are widely used in the logistics center, industrial production workshop, storage warehouse. Many of our clients hail from the e-commerce, express, food, beverage, garment, textile, furniture and home appliances industry.

    How many countries have you exported to?
    YIFAN:: United States, India, Bangladesh, UAE, Kenya, Indonesia, Pakistan, Malaysia, Thailand, Sri Lanka, the Philippines, Saudi Arabia, Singapore, France, Canada, etc.

    Ningbo YiFan Conveyor Equipment Co.,Ltd has built a comprehensive, professional and thoughtful conveyor manufacturer solutions for its customers. It can be widely seen in logistics, ports, docks, stations, airports, etc. The sales of the conveyor manufacturer also contributes to the quality of the service. It can be widely seen in logistics, ports, docks, stations, airports, etc.
