    Overview
    Quick Details
    Applicable Industries:Garment Shops, Food & Beverage Factory, Retail, Food Shop, Food & Beverage Shops, Other, Advertising Company, Distribution Center, E-business Warehouse, Store, Third Party Logistics, Packaging Company
    After Warranty Service:Video technical support, Online support
    Local Service Location:None
    Showroom Location:None
    Condition:New
    Material:Carbon Steel
    Material Feature:Fire Resistant
    Structure:Roller Conveyor
    Place of Origin:Zhejiang, China
    Brand Name:YiFan
    Voltage:AC 110V/220V/380V, AC 110V/220V/380V
    Power:750W
    Dimension(L*W*H):L6000*W600*H700/1000 mm
    Warranty:1 Year
    After-sales Service Provided:Free spare parts
    Width or Diameter:600mm
    Machinery Test Report:Not Available
    Video outgoing-inspection:Provided
    Marketing Type:Hot Product 2020
    Warranty of core components:1 Year
    Core Components:Motor, Gear, Frequency Inverter
    Roller:600*50mm galvanized steel roller
    Roller Center Gap:Max.140mm
    Motor:90W,Zhongda brand
    Side Links:5mm thickness galvanized curved join plates
    Adjustable Legs:32*32 outer tube with 30*30 inner tube
    Adjustable Height:700-1000mm
    Control Box:Forward/Stop/Reverse,Emergency Stop
    Caster:5'' swivel lockable caster
    Extendable Length:2550-6000mm
    Product Overview

    100KG LOAD V-BELT FLEXIBLE POWERED ROLLER CONVEYOR

    100KG LOAD V-Belt Flexible Powered Roller Conveyor is absolutely an durable & expandable motorized roller conveyor with Max. load capacity of 100kg/m.It can be operation in two directions with adjustable speed and working height. Having enough power supply by one mini motor per meter, it is well qualified to intensively transport goods especially with flat bottom in the warehouse, workshop, factory, harbor, dock, etc. In addition, it can be applied to such situations as production-packing line, temporary conveying line and goods distribution line. It satisfies the easy, quick and efficient goods delivery.
    Specification Roller Width: 600mm or 800mm Adjustable Height: 700-1000mm Extendable Length: 2550-6000mm Load Capacity: 100kg/m Control Box: Forward/Stop/Reverse,Emergency Stop Voltage: 220V,1-Phase or 380V, 3-Phase Motor: 90W, Zhongda brand Caster: 5" swivel lockable casters Side Links: 5mm thickness galvanized joint plates
    Power flexible roller conveyor,motorized flexible roller conveyor 6
    Power flexible roller conveyor,motorized flexible roller conveyor 8
    Close Condition
    Power flexible roller conveyor,motorized flexible roller conveyor 10
    180 degree bend
    Power flexible roller conveyor,motorized flexible roller conveyor 12
    90 degree bend
    Model List
    Model
    Open Length
    (mm)
    Close Length
    (mm)
    Adjustable Height
    (mm)
    Roller Width
    (mm)
    Motor Power
    (w)
    FPR-V6
    6000
    2550
    700-1000
    600,800
    540
    FPR-V7.2
    7200
    3060
    700-1000
    600,800
    630
    FPR-V8.4
    8400
    3570
    700-1000
    600,800
    720
    FPR-V9.6
    9600
    4080
    700-1000
    600,800
    810
    FPR-V10.8
    10800
    4590
    700-1000
    600,800
    900
    FPR-V12
    12000
    5100
    700-1000
    600,800
    990
    FPR-V13.2
    13200
    5610
    700-1000
    600-800
    1080
    FPR-V14.4
    14400
    6120
    700-1000
    600-800
    1170
    FPR-V15.6
    15600
    6630
    700-1000
    600-800
    1260
    FPR-V16.8
    16800
    7140
    700-1000
    600-800
    1350
    FPR-V18
    18000
    7650
    700-1000
    600-800
    1440
    FPR-V19.2
    19200
    8160
    700-1000
    600-800
    1530
    FPR-V20.4
    20400
    8670
    700-1000
    600-800
    1620
    PS: for length above 10m, we make the conveyor into to parts which joint together by hooks and air plug.
    Details Images
    Power flexible roller conveyor,motorized flexible roller conveyor 14
    50mm rollers driven by V belt
    Power flexible roller conveyor,motorized flexible roller conveyor 16
    Control box with Fwd/Stop/Rev switch
    Power flexible roller conveyor,motorized flexible roller conveyor 18
    Mobile on swivel casters with brake
    Power flexible roller conveyor,motorized flexible roller conveyor 20
    Reinforced side links
    Power flexible roller conveyor,motorized flexible roller conveyor 22
    Easy to take curve in warehouse
    Power flexible roller conveyor,motorized flexible roller conveyor 24
    Control box with Fwd/Stop/Rev switch
    Packing and Shipping
    Power flexible roller conveyor,motorized flexible roller conveyor 26
    Power flexible roller conveyor,motorized flexible roller conveyor 28
    Power flexible roller conveyor,motorized flexible roller conveyor 30
    Power flexible roller conveyor,motorized flexible roller conveyor 32
    Power flexible roller conveyor,motorized flexible roller conveyor 34
    FPR-V
    Power flexible roller conveyor,motorized flexible roller conveyor 36
    FPR-RV
    Power flexible roller conveyor,motorized flexible roller conveyor 38
    FPR-O-SUS
    This product is highly recognized with the help of a large sales network. Its front head is equipped with an anti-collision bar. The product has gained much acceptance and popularity in the field. Its front head is equipped with an anti-collision bar.
