Parcel express automatic loading and unloading conveyor system

    oops...!

    no product data.

    Go to homepage
    Overview
    Quick Details
    Applicable Industries:Garment Shops, Food & Beverage Factory, Home Use, Retail, Food Shop, Food & Beverage Shops, Other, Advertising Company, Distribution Center, E-business Warehouse, Store, Third Party Logistics, Packaging Company
    Showroom Location:None
    Condition:New
    Material:Carbon steel
    Material Feature:Fire Resistant
    Structure:Belt Conveyor
    Place of Origin:Zhejiang, China
    Brand Name:YiFan
    Voltage:220V/380V
    Power:1.5kw
    Warranty:1 Year
    Width or Diameter:600mm
    Machinery Test Report:Provided
    Video outgoing-inspection:Provided
    Marketing Type:Hot Product 2020
    Warranty of core components:1 Year
    Core Components:Motor, Bearing, Gear, Pump, Gearbox, Frequency Inverter
    Weight (KG):2000 kg
    Belt Material:PVK
    Control Panel:Load/Unload,Up/Down,Stop,Emergency Stop
    Motor Power:0.75kw,2.2kw
    Belt Speed:10-30m/min
    Boom Speed:10-12m/min
    Conveyor Height:700mm
    After Warranty Service:Video technical support
    After-sales Service Provided:Free spare parts
    Video Description
    Product Overview

    TELESCOPIC BELT CONVEYOR ( MODEL:MTBC-3S-4/5.4-600 )

    Telescopic Belt Conveyor is automatic loading/unloading equipment whose length is controllable widely used in logistics, ports, docks, stations, airports and warehouses, involving industries of post, home appliances, food, tobacco and light industry. It saves time of carrying back and forth and therefore makes the delivery work more efficient and less intensive, and also does less damage to the goods and helps enterprises decrease costs and increase efficiency and quality.

    Features
    1. In structure, the telescopic conveyor makes the common belt conveyor extendable and retractable freely. The length can be controlled at will by the buttons; and also height adjustment is available if needed.
    2. The conveyor can combine other conveying equipment such as lifting conveyors, inflexible roller/belt conveyors and assembly line, in which way an automatic conveying system is complete for production, assembly, storage, loading and unloading of goods.
    3. The conveyor can transmit items in both forward and reverse way; and some options in details: either constant or variable in conveying/telescoping speed, either fixed or movable type by adding universal wheels, and belt types of chemical fiber/PVC belt, oil-proof or cutting-proof
    Details Image



    Main control box
    Load, stop, unload, Light ON/OFF, Emergency stop




    Schneider VFD
    With Schneider VFD for adjust speed




    Safe brushes
    Side frame with brushes to avoid small items fall inside the conveyor




    Conveyor height adjustable
    Conveyor height can be customized depend on your requirements.




    Handles
    With handles to help move the conveyor around
    Reference Drawing
    Application Picture
    Model List
    Sections
    Model
    A(m)
    B(m)
    C(m)
    H(mm)
    Belt Width(mm)





    3
    FTBC-3S-4/5.4
    4
    5.4
    9.4
    800
    600/800

    FTBC-3S-4.5/6
    4.5
    6
    10.5
    800
    600/800
    FTBC-3S-5/7
    5
    7
    12
    800
    600/800
    FTBC-3S-5.4/7.3
    5.4
    7.3
    10.7
    800
    600/800
    FTBC-3S-6/8.5
    6
    8.5
    14.5
    800
    600/800
    FTBC-3S-6.5/9.4
    6.5
    9.4
    15.9
    800
    600/800
    FTBC-3S-7/9.6
    7
    9.6
    16.6
    800
    600/800




    4
    FTBC-4S-4/7
    4
    7
    11
    950
    600/800
    FTBC-4S-4.5/8.5
    4.5
    8.5
    13
    950
    600/800
    FTBC-4S-5/9.5
    5
    9.5
    14.5
    950
    600/800
    FTBC-4S-5.4/10.3
    5.4
    10.3
    15.7
    950
    600/800
    FTBC-4S-6/12
    6
    12
    18
    950
    600/800
    FTBC-4S-6.5/12.8
    6.5
    12.8
    19.3
    950
    600/800
    FTBC-4S-7/14
    7
    14
    21
    950
    600/800
    Sections
    Model
    A(m)
    B(m)
    C(m)
    H(m)
    Belt Width(mm)

    3
    MTBC-3S-4/5.4
    4
    5.4
    9.4
    1100
    600/800
    MTBC-3S-5/7
    5
    7
    12
    1100
    600/800
    MTBC-3S-6/8.5
    6
    8.5
    14.5
    1100
    600/800

    4
    MTBC-4S-4/7
    4
    7
    11
    1200
    600/800
    MTBC-4S-5/9.5
    5
    9.5
    14.5
    1200
    600/800
    MTBC-4S-6/12
    6
    12
    18
    1200
    600/800
    Sections
    Model
    A(m)
    B(m)
    L(mm)
    H(mm)
    Belt Width(mm)
    3
    ITBC-3S-4/5
    4
    5
    3000-4500
    750/1500
    600/800
    ITBC-3S-6/8
    6
    8
    3000-4500
    750/1500
    600/800
    4
    ITBC-4S-6/12
    6
    12
    3000-4500
    750/1500
    600/800
    ITBC-4S-7/14
    7
    14
    3000-4500
    750/1500
    600/800
    Company Profile
    FAQ

    Please feel free to contact us at sales@yfconveyor.com if you have any other questions.

    How long is the production time?
    YIFAN: flexible conveyor takes 1-2 weeks; truck loading conveyor and telescopic belt conveyor takes 3-4 weeks

    What is the MOQ?
    YIFAN: 1 unit

    Can your company provide OEM & ODM service
    YIFAN: yes

    Can you do customized conveyors?
    YIFAN: yes

    Do you offer installation service abroad?
    YIFAN: yes

    What is the payment terms?
    YIFAN: T/T,LC,

    What is the delivery port?
    YIFAN: Ningbo/Shanghai

    How many years have you been in this industry?
    YIFAN: 10 years

    What is the HS code?
    YIFAN: 84283300,84283920,84283990

    Is YIFAN a trading company or factory?
    YIFAN: we are a trading company but have long-term cooperation factory, who only supply from us.

    Which industry can your conveyors be applied to?
    YIFAN: our conveyors are widely used in the logistics center, industrial production workshop, storage warehouse. Many of our clients hail from the e-commerce, express, food, beverage, garment, textile, furniture and home appliances industry. How many countries have you exported to?
    YIFAN:: United States, India, Bangladesh, UAE, Kenya, Indonesia, Pakistan, Malaysia, Thailand, Sri Lanka, the Philippines, Saudi Arabia, Singapore, France, Canada, etc.

    Ningbo YiFan Conveyor Equipment Co.,Ltd has built a comprehensive, professional and thoughtful conveyor manufacturer solutions for its customers. The product is available in a vast range of width and models. In Ningbo YiFan Conveyor Equipment Co.,Ltd, you can get global optimum acquisition price for any required conveyor manufacturer. The product is available in a vast range of width and models.
