    Overview
    Quick Details
    Applicable Industries:Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other, Hotels, Restaurant
    After Warranty Service:Video technical support, Online support
    Local Service Location:None
    Showroom Location:None
    Condition:New
    Material:Carbon Steel
    Material Feature:Fire Resistant
    Structure:Inclining belt Conveyor
    Place of Origin:Zhejiang, China
    Brand Name:YiFan
    Voltage:220V 1 phase/ 380V 3 phase
    Power:1.5kw,2.2kw
    Dimension(L*W*H):L4700*W600*H700/2500 mm
    Warranty:1 Year
    After-sales Service Provided:Online support
    Width or Diameter:belt 600 mm/800 mm
    Machinery Test Report:Not Available
    Video outgoing-inspection:Provided
    Marketing Type:Hot Product 2020
    Warranty of core components:1 Year
    Core Components:Motor, Gear, Pump, Gearbox
    Weight (KG):4000 kg
    Belt Material:PVC
    Front Tongue:4.2m powered roller conveyor
    Loading Height:2500mm
    Adjustable Speed:10-20m/min
    Discharge Height:700mm
    Motor Power:1.5kw,2.2kw
    Control Panel:Belt Forward, Stop, Reverse,Up, Down, Emergency Stop
    Caster:6" heavy duty swivel lockable PU casters
    Packing Size:L4900*W1240*H1625mm,850KGS
    Product Overview

    TLC-P600 Truck Loading Conveyor

    The Truck Loading Conveyor is consist of two parts:
    Front Flexible Tongue and Inclined Belt Conveyor.
    It is designed to endure the rigorous demands of warehouse,harbor,airport,dock,distribution center and parcel handling hubs around the world,which is extremely flexible and easily move into position on braked swivel castors.It largely facilitates goods handling work and increase work efficiency.
    Inclined truck loading and unloading conveyor for vehicle unloading 8

    PART 1.Flexible Powered Roller Conveyor-O belt

    Size(mm):L4800/1840*W600*H700/1000
    Variable Speed(m/min):10-18
    Load Capacity(kg/m):50
    Power(kw):0.36
    *Belt:high quality O ring PU belt
    *Roller:Dia 50mm galvanized steel roller,roller center Max 130mm
    *Caster:5'' swivel lockable casters
    *Frame:3.5mm thickness galvanized curved join plates with better load
    *Leg:32×32 outer tube with 25×25 inner tube,spray
    paint black
    *Control Box:Forward/Stop/Reverse,Emergency Stop
    Inclined truck loading and unloading conveyor for vehicle unloading 10

    PART 2.Inclined Belt Conveyor

    Size(mm):L4700*W600*H700/2500
    Variable Speed(m/min):10-20
    Load Capacity(kg/m):50
    Power(kw):3.7
    *Standard Belt: 600*3mm anti-skiding stripy belt Forbo Seigling
    *Option Belt: 600*5mm rough top green PVC belt
    *Caster:6" heavy duty swivel lockable PU casters
    *Control Panel: Belt Forward, Stop, Reverse,Up, Down, Emergency Stop
    *Voltage:220V,1-Phase,50Hz or 380V,3-Phase,50Hz
    *Part 1+2 Packing Details:
    L4900*W1240*H1625mm,850KGS
    Technical Parameters
    Inclined truck loading and unloading conveyor for vehicle unloading 12
    Model
    Belt Width(mm)
    L1(mm)
    L2(mm)
    L3(mm)
    L(mm)
    H1(mm)
    H1(mm)
    TLC-P600
    600
    900
    3700
    1800
    4200
    700
    700-2500
    Inclined truck loading and unloading conveyor for vehicle unloading 14
    Details Image
    Inclined truck loading and unloading conveyor for vehicle unloading 16
    With Load,Unload,Up,Down,Emergency Stop,Speed Kob buttons
    Inclined truck loading and unloading conveyor for vehicle unloading 18
    Control panel covered by a lockable door
    Inclined truck loading and unloading conveyor for vehicle unloading 20
    PVC anti-skiding belt
    Inclined truck loading and unloading conveyor for vehicle unloading 22

    With two side guards

    Inclined truck loading and unloading conveyor for vehicle unloading 24

    Mobile on lockable swivel casters


    Inclined truck loading and unloading conveyor for vehicle unloading 26

    Belt tighten system

    Inclined truck loading and unloading conveyor for vehicle unloading 28
    Flexible conveyor bracket and main conveyor are joint by screws
    Inclined truck loading and unloading conveyor for vehicle unloading 30
    Screw lift system
    Inclined truck loading and unloading conveyor for vehicle unloading 32
    Lock the foot to be more stable when rise up
    Successful Project
    Inclined truck loading and unloading conveyor for vehicle unloading 34

    Inclined truck loading and unloading conveyor for vehicle unloading 36

    Inclined truck loading and unloading conveyor for vehicle unloading 38

    Installation Instructions
    Inclined truck loading and unloading conveyor for vehicle unloading 40
    Inclined truck loading and unloading conveyor for vehicle unloading 42
    Inclined truck loading and unloading conveyor for vehicle unloading 44
    Inclined truck loading and unloading conveyor for vehicle unloading 46
    Inclined truck loading and unloading conveyor for vehicle unloading 48
    Inclined truck loading and unloading conveyor for vehicle unloading 50
    Inclined truck loading and unloading conveyor for vehicle unloading 52
    Inclined truck loading and unloading conveyor for vehicle unloading 54
    SIMILAR PRODUCTS
    Inclined truck loading and unloading conveyor for vehicle unloading 56
    Company Profile
    Inclined truck loading and unloading conveyor for vehicle unloading 58
    Inclined truck loading and unloading conveyor for vehicle unloading 60
    Inclined truck loading and unloading conveyor for vehicle unloading 62
    Inclined truck loading and unloading conveyor for vehicle unloading 64
    Inclined truck loading and unloading conveyor for vehicle unloading 66
    Inclined truck loading and unloading conveyor for vehicle unloading 68
    FAQ
    Please feel free to contact us at sales02@yfconveyor.com if you have any other questions.
    How long is the production time?
    YIFAN: flexible conveyor takes 1-2 weeks; truck loading conveyor and telescopic belt conveyor takes 3-4 weeks

    What is the MOQ?
    YIFAN: 1 unit

    Can your company provide OEM & ODM service?
    YIFAN: yes

    Can you do customized conveyors?
    YIFAN: yes

    Do you offer installation service abroad?
    YIFAN: yes

    What is the payment terms?
    YIFAN: T/T,LC,

    What is the delivery port?
    YIFAN: Ningbo/Shanghai

    How many years have you been in this industry?
    YIFAN: 10 years

    What is the HS code?
    YIFAN: 84283300,84283920,84283990

    Is YIFAN a trading company or factory?
    YIFAN: we are a trading company but have long-term cooperation factory, who only supply from us.

    Which industry can your conveyors be applied to?
    YIFAN: our conveyors are widely used in the logistics center, industrial production workshop, storage warehouse. Many of our clients hail from the e-commerce, express, food, beverage, garment, textile, furniture and home appliances industry.

    How many countries have you exported to?
    YIFAN:: United States, India, Bangladesh, UAE, Kenya, Indonesia, Pakistan, Malaysia, Thailand, Sri Lanka, the Philippines, Saudi Arabia, Singapore, France, Canada, etc.
