Flexible motorized roller conveyor for loading and unloading bags into trucks containers-YiFan Conveyor

Overview

Quick Details

Applicable Industries:Garment Shops, Food & Beverage Factory, Retail, Food Shop, Food & Beverage Shops, Other, Advertising Company, Distribution Center, E-business Warehouse, Store, Third Party Logistics, Packaging Company

Showroom Location:None

Condition:New

Material:Carbon steel

Material Feature:Fire Resistant

Structure:Roller Conveyor

Place of Origin:Zhejiang, China

Brand Name:YiFan

Voltage:AC 110V/220V/380V, AC 110V/220V/380V

Power:750W

Dimension(L*W*H):L6000*W600*H700/1000 mm

Warranty:1 Year

Width or Diameter:600mm

Machinery Test Report:Not Available

Video outgoing-inspection:Provided

Marketing Type:Hot Product 2020

Warranty of core components:1 Year

Core Components:Motor, Gear, Frequency Inverter

Weight (KG):350 kg

Extendable Length:2750-6000mm

Roller Width:600*50mm galvanized steel roller

Adjustable Height:700-1000mm

Roller Center Gap:Max.140mm

Motor:90W,Zhongda brand

Side Links:5mm thickness galvanized join plates

Adjustable Legs:32*32 outer tube with 30*30 inner tube

Control Box:Forward/Stop/Reverse,Emergency Stop

Caster:5'' swivel lockable caster

Video Description

Product Overview

V-BELT FLEXIBLE POWERED RUBBER COATED ROLLER CONVEYOR

50KG Load O-belt Flexible Powered Roller Conveyor is an extendable powered automatic roller conveyor with controllable conveying speed & direction and adjustable supporting leg height.Having enough power supply by one mini motor per section, it is well qualified to internsively transport goods especially with flat bottom in the warehouse/storehouse,workshop,factory,harbor,docks,etc.

Specification Roller Width: 600mm or 800mm Adjustable Height: 700-1000mm Extendable Length: 2750-6000mm Load Capacity: 100kg/m Control Box: Forward/Stop/Reverse,Emergency Stop Voltage: 220V,1-Phase or 380V, 3-Phase Motor: 90W, Zhongda brand Caster: 5" swivel lockable casters Side Links: 5mm thickness galvanized join plates

Open Elevation

Bend Elevation

Close Elevation

Model List

Model	Open Length (mm)	Close Length (mm)	Adjustable Height (mm)	Roller Width (mm)	Motor Power (w)
FPR-RV6	6000	2750	700-1000	600,800	450
FPR-RV7.2	7200	3300	700-1000	600,800	540
FPR-RV8.4	8400	3850	700-1000	600,800	630
FPR-RV9.6	9600	4400	700-1000	600,800	720
FPR-RV10.8	10800	4950	700-1000	600,800	810
FPR-RV12	12000	5500	700-1000	600,800	900
FPR-RV13.2	13200	6050	700-1000	600,800	990
FPR-RV14.4	14400	6600	700-1000	600,800	1080
FPR-RV15.6	15600	7150	700-1000	600,800	1170
FPR-RV16.8	16800	7700	700-1000	600,800	1260
FPR-RV18	18000	8250	700-1000	600,800	1350
FPR-RV19.2	19200	8800	700-1000	600,800	1440
FPR-RV20.4	20400	9350	700-1000	600,800	1530
PS: for length above 10m, we make the conveyor into to parts which joint together by hooks and air plug.

Details Images

Reinforced double H shape legs with nice load capacity

With handle on the legs to help move the conveyor around

Adjustable Height: 700-1000mm or 800-1200mm

Each conveyor with one independent control box, Fwd/Stop/Rev

5mm thick heavy duty side links with good load capacity

Each conveyor leg with a min motor

Adopt rubber coated rollers to avoid items getting slippery

Rollers driven by high quality V belt

Mobile on 5" swivel casters with brakes

Packing and Shipping

Company Profile

FAQ

Please feel free to contact us at sales@yfconveyor.com if you have any other questions.

How long is the production time?
YIFAN: flexible conveyor takes 1-2 weeks; truck loading conveyor and telescopic belt conveyor takes 3-4 weeks

What is the MOQ?
YIFAN: 1 unit

Can your company provide OEM & ODM service
YIFAN: yes

Can you do customized conveyors?
YIFAN: yes

Do you offer installation service abroad?
YIFAN: yes

What is the payment terms?
YIFAN: T/T,LC,

What is the delivery port?
YIFAN: Ningbo/Shanghai

How many years have you been in this industry?
YIFAN: 10 years

What is the HS code?
YIFAN: 84283300,84283920,84283990

Is YIFAN a trading company or factory?
YIFAN: we are a trading company but have long-term cooperation factory, who only supply from us.

Which industry can your conveyors be applied to?
YIFAN: our conveyors are widely used in the logistics center, industrial production workshop, storage warehouse. Many of our clients hail from the e-commerce, express, food, beverage, garment, textile, furniture and home appliances industry. How many countries have you exported to?
YIFAN：: United States, India, Bangladesh, UAE, Kenya, Indonesia, Pakistan, Malaysia, Thailand, Sri Lanka, the Philippines, Saudi Arabia, Singapore, France, Canada, etc.

High quality, competitive price and the top level after-sale service are Ningbo YiFan Conveyor Equipment Co.，Ltd's business base. The specifications, load capacity, and other special functions can be customized. Product research center is equipped in YiFan Conveyor for the innovation of conveyor manufacturer. The specifications, load capacity, and other special functions can be customized.
