Customized truck loading unloading low noise telescopic conveyor belt
5.0
Start Port:
Sea freight
Payment:
1 - 5(Sets):30(days),>5(Sets):Negotiable(days)
MOQ:
[{'sku_name': '50KG', 'sku_img': None, 'sku_id': '100005813:-1;'}]
Model:
[{'sku_name': 'SLAT CONVEYOR', 'sku_img': None, 'sku_id': '191284229:430360791;'}, {'sku_name': 'Other', 'sku_img': None, 'sku_id': '191284229:4;'}]
Load Capacity:
[{'sku_name': 'ITBC-3S-5/7-800', 'sku_img': None, 'sku_id': '3:-1;'}]
Certification:
Customized logo (Min. Order: 1 Sets),Customized packaging (Min. Order: 1 Sets),Graphic customization (Min. Order: 1 Sets)
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Overview
Quick Details
Applicable Industries:Garment Shops, Food & Beverage Factory, Home Use, Retail, Food Shop, Food & Beverage Shops, Other, Advertising Company, Distribution Center, E-business Warehouse, Store, Third Party Logistics, Packaging Company
After Warranty Service:Video technical support, Online support, Spare parts
Local Service Location:None
Showroom Location:None
Condition:New
Material:Carbon Steel
Material Feature:Fire Resistant
Structure:Belt Conveyor
Place of Origin:Zhejiang, China
Brand Name:YiFan
Voltage:AC 110V/220V/380V, 220V,1-Phase,50Hz or 380V,3-Phase,50Hz
Power:Other
Dimension(L*W*H):L5000/12000*W600*H750 mm
Warranty:1 Year
After-sales Service Provided:Free spare parts
Width or Diameter:600mm
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Marketing Type:Hot Product 2020
Warranty of core components:1 Year
Core Components:Motor, Bearing, Gear, Pump, Gearbox, Frequency Inverter
Belt Material:PVC,PVK
Control Panel:Belt Forward, Stop, Reverse,Up, Down, Emergency Stop
Packing Details:L5100*W1400*H1100mm,4000KGS
Motor Power:0.75kw,2.2kw
Belt Width:800mm
Belt Speed:10-30m/min
Boom Speed:10-12m/min
Conveyor Height:adjust by hydraulic
Load Capacity:50kg/m
Product Overview
( INCLINED TYPE ) TELESCOPIC BELT CONVEYOR
Telescopic Belt Conveyor is an automatic loading/unloading equipment whose length is controllable widely used in logistics, ports, docks, stations, airports and warehouses, involving industries of post, home appliances, food, tobacco and light industry. It saves time of carrying back and forth and therefore makes the delivery work more efficient and less intensive, and also does less damage to the goods and helps enterprises decrease costs and increase efficiency and quality.
Technical Parameters | ||
Fixed Length | 5m | |
Extension Length | 7m | |
Total Length | 12m | |
Tail Boom | 1.1m | |
Belt Spec | 800mm width Siegling PVK belt | |
Loading Height | 775mm | |
Discharge Height | 1175-2930mm | |
Belt Direction | Forward & reverse | |
Max. Load Capacity | 60kg/m | |
Belt Driven Motor | 3.0 kw. SEW | |
Telescopic Motor | 0.75kw. SEW | |
Tail Boom Motor | 1.5kw. SEW | |
Hydraulic Power Pack | 2.2kw | |
Machine Total Power | 7.45kw | |
Main Electric Components | Schneider, including abnormal fault automatic detection alarm device | |
Telescopic Chain | Donghua, Hangzhou | |
Power Cord Length | 5-10m | |
Standard Color | BLUE, RAL5015 | |
Voltage | 380V, three phase, 50Hz | |
Drawing
Details Image
Telescopic belt conveyor combine with flexible powered roller conveyor
Backside with inclined belt conveyor
Extendable in length
Main control box: forward/reverse,up/down, Light ON/OFF,stop,emergency stop
With hydraulic lift systemWith hydraulic lift system
Mobile on heavy duty casters
Similar Products
Successful Project
Project in Bangladesh Tea Products Factory
Vertical lifting 60KG tea bags from 2nd floor to first floor and load directly into trucks.
Company Profile
The use of this product means saving time and labor costs. Thanks to its high efficiency, it can quickly finish tasks that people can not do. It is widely used in industries like the express, food & beverage, health & beauty, home appliances, etc.
The product can significantly liberate people from heavy-duty and monotonous work, allowing people to spend time focusing on other important tasks. It is widely used in industries like the express, food & beverage, health & beauty, home appliances, etc.
