    Overview
    Quick Details
    Applicable Industries:Garment Shops, Food & Beverage Factory, Home Use, Retail, Food Shop, Food & Beverage Shops, Other, Advertising Company, Distribution Center, E-business Warehouse, Store, Third Party Logistics, Packaging Company
    After Warranty Service:Video technical support, Online support, Spare parts
    Local Service Location:Egypt, None
    Showroom Location:None
    Condition:New
    Material:Carbon Steel
    Material Feature:Fire Resistant
    Structure:Belt Conveyor
    Place of Origin:Zhejiang, China
    Brand Name:YiFan
    Voltage:AC 110V/220V/380V, 220V,1-Phase,50Hz or 380V,3-Phase,50Hz
    Power:Other
    Dimension(L*W*H):L6000/12000*W600*H950 mm
    Warranty:1 Year
    After-sales Service Provided:Free spare parts
    Width or Diameter:600mm
    Machinery Test Report:Provided
    Video outgoing-inspection:Provided
    Marketing Type:Hot Product 2020
    Warranty of core components:1 Year
    Core Components:Motor, Bearing, Gear, Pump, Gearbox, Frequency Inverter
    Belt Material:PVK
    Control Panel:Belt Forward, Stop, Reverse,Up, Down, Emergency Stop
    Packing Details:L6100*W1400*H1000mm,4000KGS
    Motor Power:0.75kw,2.2kw
    Belt Width:600mm,800mm
    Belt Speed:10-30m/min
    Boom Speed:10-12m/min
    Conveyor Height:adjust by hydraulic
    Load Capacity:50kg/m
    Video Description
    Product Overview

    ( MOVABLE TYPE ) TELESCOPIC BELT CONVEYOR

    Telescopic Belt Conveyor is an automatic loading/unloading equipment whose length is controllable widely used in logistics, ports, docks, stations, airports and warehouses, involving industries of post, home appliances, food, tobacco and light industry. It saves time of carrying back and forth and therefore makes the delivery work more efficient and less intensive, and also does less damage to the goods and helps enterprises decrease costs and increase efficiency and quality.
    Technical Parameters
    Fixed Length
    7m
    Extension Length
    14m
    Total Length
    21m
    Belt Spec
    600mm width PVK belt
    Belt Top Heigh
    1250mm, adjustable
    Belt Direction
    Forward & reverse
    Max. Load Capacity
    50kg/m
    Belt Driven Motor
    2.2 kw. SEW
    Telescopic Motor
    0.75kw. SEW
    Tail Boom Motor
    1.5kw. SEW
    Hydraulic Power Pack
    1.5kw
    Telescopic Chain
    Donghua, Hangzhou
    Power Cord Length
    10m
    Standard Color
    BLUE, RAL5015
    Voltage
    380V, three phase, 50Hz
    Model List
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 8
    Details Image
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 10
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 12
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 14
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 16
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 18
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 20
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 22
    Company Profile
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 24
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 26
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 28
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 30
    Container and Truck Loading Unloading Telescopic Belt Conveyor Equipment 32
    The customer's needs, expectations and satisfaction continue to be achieved with this product. High-quality steel rollers ensure a smooth transfer. The product is popular in the market due to a broad marketing channel. High-quality steel rollers ensure a smooth transfer.
