JINGU TGSS scraper chain conveyor is a new development design generation product. It has been widely applied for grain, oils, feed, biomass, fertilizer, port terminal, etc. This machine includes heavy duty type and light type to satisfy different requirement of customers. Its structure highlight is compact structure, good seal, low noise and high conveying efficiency.
Key Features:
Model | Capacity (m3/h) | Trunk Section (mm×mm) | Linear Speed(m/s) |
TGSS25 | 50~100 | 250×250 | 0.35-0.63 |
TGSS32 | 90~150 | 320×320 | 0.35-0.63 |
TGSS40 | 150~280 | 400×420 | 0.35-0.63 |
TGSS50 | 180~350 | 500×420 | 0.35-0.63 |
TGSS63 | 280~640 | 630×500 | 0.35-0.8 |
TGSS80 | 390~870 | 800×540 | 0.35-0.8 |
TGSS100 | 480~1400 | 1000×540 | 0.35-1.0 |
TGSS120 | 700~2000 | 1200×650 | 0.35-1.0 |
*Capacities based on dry, free flowing, bulk grain material with proper loading and discharging conditions at 0.75kg/m3 | |||
*General specifications and dimensions are subject to change without notice. |
Payment Terms:
1. L/C at sight;
2. T/T: 30% deposit by T/T, 70% balance by T/T before shipment.
Trade Terms:
EXW or FOB Qingdao Port or CIF Destination Port
Packing Detail:
Neutral packing, export standard package include EPE foam.
