    The power roller telescopic conveyor machine is mainly used in the back-end logistics, e-commerce, warehousing, express and other industries, and can be used jointly with intelligent sorting equipment to help the factory warehouse solve the problem of large cargo volume and low loading efficiency. Truly save time, labor and cost.

    Labor saving: saving the labor of unloading

    Time saving: the speed of 10-30m/min can be adjusted to improve work efficiency

    Cost saving: saves a lot of manual handling costs

    Application scenarios are wide: logistics warehouse, factory manufacturing, dock, fruit industry, agricultural products, airports


    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 6

    FPR-V Expandable roller conveyor

    WAREHOUSE DIY FLEXIBLE POWER TELESCOPIC ROLLER CONVEYOR-V BELT

    We made a segmented design of the machine, 3 sections for a unit, each electric control cabinet can drive 11 units, that is, 39.6 meters long. Each electric control cabinet with how many units can be arbitrarily selected, as long as no more than 11. This design allows users to adjust the length of the machine at any time according to the needs of the site. More flexible, while reducing unnecessary power consumption, more energy saving and environmental protection.

    TECHNICAL PARAMETERS

    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 7

    Belt

    High quality Yuanyang V belt

    Roller

    Dia 50*1.5mm galvanized steel roller, Max. gap138mm center to center

    Motor

    90W/120W electronic governor motor

    Frame

    5mm thickness reinforced X shape side links

    Leg

    32×32 powder coated tube with 25×25 galvanized tube inside

    Caster

    5" high quality swivel lockable polyurethane casters

    Control Box

    Forward/Stop/Reverse

    Frequency Inverter

    Delta

    MODEL LIST

    Model

    Open Length
    (mm)

    Close Length
    (mm)

    Roller Width
    (mm)

    AdjustableHeight
    (mm)

    VariableSpeed
    (m/min)

    Max.Load
    (kg/㎡)

    Motor Power
    (w)

    FPR-V4.8

    4800

    2040

    600/800

    700-1000

    10-20

    100

    450

    FPR-V6

    6000

    2550

    600/800

    700-1000

    10-20

    100

    540

    FPR-V7.2

    7200

    3060

    600/800

    700-1000

    10-20

    100

    630

    FPR-V.48

    8400

    3570

    600/800

    700-1000

    10-20

    100

    720

    FPR-V9.6

    9600

    4080

    600/800

    700-1000

    10-20

    100

    810

    FPR-V10.8

    10800

    4590

    600/800

    700-1000

    10-20

    100

    900

    FPR-V12

    12000

    5100

    600/800

    700-1000

    10-20

    100

    990

    FPR-V13.2

    13200

    5610

    600/800

    700-1000

    10-20

    100

    1080

    FPR-V14.4

    14400

    6120

    600/800

    700-1000

    10-20

    100

    1170

    FPR-V15.6

    15600

    6630

    600/800

    700-1000

    10-20

    100

    1260

    FPR-V16.8

    16800

    7140

    600/800

    700-1000

    10-20

    100

    1350

    FPR-V18

    18000

    7650

    600/800

    700-1000

    10-20

    100

    1440

    FPR-V19.2

    19200

    8160

    600/800

    700-1000

    10-20

    100

    1530

    FPR-V20.4

    20400

    8670

    600/800

    700-1000

    10-20

    100

    1620

    SHOW DETAILS

    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 8
    Electric Box control running forward/backward, stop, emergency stop
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 9
    Driven by V belt which pass more power to the rollers
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 10
    Each leg with a handle to help move conveyor around
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 11
    Universal mobile PU castors
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 12
    H Shaped reinforced supporting legs with adjustable height
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 13
    5mm thickness cross side links with nice load

    Application 1

    Load 50KG tea bags front production line to store house in tea products factory.

    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 14
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 15
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 16

    Application 2

    Extendable motorized roller conveyor can be used in warehouse for transport cartons,boxes from store room to another place.It occupy small place and can easly take curve.

    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 17
    Factory/Warehouse DIY Power Roller Telescopic Conveyor Machine 18
